Q: Key Specifications

Main unit input: 220-240V~ 50Hz/60Hz 150mA Output primary tip vibration excursion: ≤90μm Output half-excursion force: <2N Output tip vibration frequency: 28kHz±3kHz Output power: 3W to 20W Main unit fuse: T0.5AL 250V Water pressure: 0.01MPa to 0.5MPa Weight of the main unit: 1.8kg Operating mode: Continuous operation Type of protection against electric shock: class II equipment Degree of protection against electric shock: Type BF applied part Applied part of the equipment: handpiece and tip

Q: Packaging

1 x Main unit 1 x Detachable handpiece 1 x Power cord 1 x Footswitch 7 x Scaling tip GD4,GD12,PD1,PD3,PD8,ED62,ED60 1 x Torque wrench 1 x Endo wrench 1 x Water pipe 1 x Quick-connector for Water 6 x Waterproof “O” ring 6pc 10 x Bottle sealed ring 3 x Handpiece lock ring 1 x 700 mL water bottle 1 x lnstruction manual 1 x Warranty card 1 1 x Packing list

Q: Directions to Use

Preparation: Before use, check the unit and handpiece for any visible damage or defects. Make sure the scaler is properly connected to a power source and turned on. Tip selection: Select the appropriate tip for the procedure and attach it to the handpiece. The scaler comes with a range of tips suitable for different procedures, such as supragingival scaling, subgingival scaling, and implant maintenance. Make sure the tip is securely fastened to the handpiece before use. Power and water adjustments: Adjust the power setting to the desired level using the power adjustment knob. The scaler has a range of power settings from low to high. Adjust the water flow rate to the appropriate level using the water adjustment knob. The water flow rate can be adjusted to suit patient comfort and the specific procedure. Positioning and angulation: Place the tip of the scaler against the tooth surface, angling it at a 45-degree angle towards the gum line. Apply moderate pressure and use a back-and-forth motion to remove plaque, tartar, or stains. Avoid using excessive pressure or angling the tip too aggressively, as this can cause discomfort or damage to the tooth surface. Water spray function: Use the water spray function to rinse the tip and flush away debris from the teeth. The scaler has a water spray function that can be activated by pressing the water control button on the handpiece. Moving on to the next tooth: Move on to the next tooth and repeat the process until all teeth have been cleaned. When moving to a new tooth, adjust the angle and position of the tip accordingly. Completion of procedure: Once the procedure is complete, turn off the scaler and detach the tip from the handpiece.

Q: Additional Info

Country of Origin: PRC Manufacturer: Woodpecker

Q: Warranty

Manufacturer/Importer Warranty of 1 Year on all the parts of the product & 5 years Warranty (from the date of invoice) on PCB (Power Circuit Board). Physical damage is not cover in any case Service and Warranty are handled by the manufacturer/importer directly for this product Supreme Dental will not be liable to replace the Products and the liability to replace any such Product is that of the Manufacturer/Importer Supreme Dental and the Buyer acknowledge that the Products purchased/used are a subject matter of original Manufacturer/Importer’s warranties only Any or all claims in relation to returns and replacement shall be made to the concerned Manufacturer/Importer only and Supreme Dental may assist the customer in registering a request to get the Product replaced or serviced. The Buyer acknowledges that the Products once sold will not be exchanged or taken back unless the seal of the package or the Product is intact or not altered in any manner or is not tampered as the case may be.

Question 1

Features

Accepted Answer

Efficient plaque and tartar removal
Versatile tip selection for different procedures
Adjustable power settings for customized treatment
LED illumination for improved visibility
Water spray function for cooling and rinsing
Ergonomic design for comfortable use
Autoclavable handpieces and tips for easy sterilization
Intelligent feedback systems for optimal scaling effect
Easy maintenance and cleaning

Question 2

Description

Accepted Answer

Portable Ultrasonic LED Scaler with Scaling, Periodontal, and Endodontic Modes

Question 3

Key Specifications

Accepted Answer

Main unit input: 220-240V~ 50Hz/60Hz 150mA
Output primary tip vibration excursion: ≤90μm
Output half-excursion force: <2N
Output tip vibration frequency: 28kHz±3kHz
Output power: 3W to 20W
Main unit fuse: T0.5AL 250V
Water pressure: 0.01MPa to 0.5MPa
Weight of the main unit: 1.8kg
Operating mode: Continuous operation
Type of protection against electric shock: class II equipment
Degree of protection against electric shock: Type BF applied part
Applied part of the equipment: handpiece and tip

Question 4

Packaging

Accepted Answer

1 x Main unit
1 x Detachable handpiece
1 x Power cord
1 x Footswitch
7 x Scaling tip GD4,GD12,PD1,PD3,PD8,ED62,ED60
1 x Torque wrench
1 x Endo wrench
1 x Water pipe
1 x Quick-connector for Water
6 x Waterproof “O” ring 6pc
10 x Bottle sealed ring
3 x Handpiece lock ring
1 x 700 mL water bottle
1 x lnstruction manual
1 x Warranty card 1
1 x Packing list

Question 5

Directions to Use

Accepted Answer

Preparation: Before use, check the unit and handpiece for any visible damage or defects. Make sure the scaler is properly connected to a power source and turned on.
Tip selection: Select the appropriate tip for the procedure and attach it to the handpiece. The scaler comes with a range of tips suitable for different procedures, such as supragingival scaling, subgingival scaling, and implant maintenance. Make sure the tip is securely fastened to the handpiece before use.
Power and water adjustments: Adjust the power setting to the desired level using the power adjustment knob. The scaler has a range of power settings from low to high. Adjust the water flow rate to the appropriate level using the water adjustment knob. The water flow rate can be adjusted to suit patient comfort and the specific procedure.
Positioning and angulation: Place the tip of the scaler against the tooth surface, angling it at a 45-degree angle towards the gum line. Apply moderate pressure and use a back-and-forth motion to remove plaque, tartar, or stains. Avoid using excessive pressure or angling the tip too aggressively, as this can cause discomfort or damage to the tooth surface.
Water spray function: Use the water spray function to rinse the tip and flush away debris from the teeth. The scaler has a water spray function that can be activated by pressing the water control button on the handpiece.
Moving on to the next tooth: Move on to the next tooth and repeat the process until all teeth have been cleaned. When moving to a new tooth, adjust the angle and position of the tip accordingly.
Completion of procedure: Once the procedure is complete, turn off the scaler and detach the tip from the handpiece.

Question 6

Additional Info

Accepted Answer

Country of Origin: PRC
Manufacturer: Woodpecker

Question 7

Warranty

Accepted Answer

Manufacturer/Importer Warranty of 1 Year on all the parts of the product & 5 years Warranty (from the date of invoice) on PCB (Power Circuit Board).
Physical damage is not cover in any case
Service and Warranty are handled by the manufacturer/importer directly for this product
Supreme Dental will not be liable to replace the Products and the liability to replace any such Product is that of the Manufacturer/Importer
Supreme Dental and the Buyer acknowledge that the Products purchased/used are a subject matter of original Manufacturer/Importer’s warranties only
Any or all claims in relation to returns and replacement shall be made to the concerned Manufacturer/Importer only and Supreme Dental may assist the customer in registering a request to get the Product replaced or serviced.
The Buyer acknowledges that the Products once sold will not be exchanged or taken back unless the seal of the package or the Product is intact or not altered in any manner or is not tampered as the case may be.

Free Shipping for all Order of ₹ 30000

Woodpecker D600 LED Ultrasonic Scaler
