₹140,000.00
Please enter PIN code to check delivery time & Pay on Delivery Availability
| Features | Passion Delux |
| Electrically Operating Underhanging Dental Chair Unit | Yes |
| Warranty on the Up/ Down & Back rest Motor | 4 Years |
| Warranty on the chair | 2 Years |
| LED Light | Yes |
| Inbuilt pneumatic Suction | Yes |
| Operating points | 2 |
| X- ray film viewer | Yes |
| Airrotor point | 2 |
| Movable Airrotor Stand | No |
| Monitor Arm | Optional |
| Movable Assistant Tray | Yes |
| Spitoon Type | Glass |
| Autoflush & Cup Filler System | Manual |
| Zero & Syncope Position | Yes |
| Airrotor foot control | Electrical |
| Two 3 – Way Syringe | Yes |
| Dental Stool | Yes |
Hardware Specifications
| Power : | 220 Volt |
| Frequency : | 50 -60 Hz. |
| Illumination of dental light | 8000-25000 Lux |
| Intensity of X-ray viewer | ≥2000cd/m2 |
| Capacitive loads of dental chair | 1323N (135kg) |
| Capacitive loads of Dentist Unit tray | 2.5kg |
| High-speed air turbine handpiece | Idling speed≥35×10 3 r/min (Air pressure:0.22Mpa) |
| Low-speed air turbine handpiece | Idling speed≥18×10 3 r/min (Air pressure:0.3Mpa) |
| The highest position of the patient chair from the ground | 830mm |
| The lowest position of the patient chair from the ground | 380mm |
| Backrest movement range | 107°- 177° |
| Headrest extension range | 0-150mm |
| Air supply pressure | 0.55-0.80Mpa |
| Water supply pressure | 0.2-0.4Mpa |
Environmental Specifications
| Operating temperature | 5℃～40℃ |
| Operating humidity | ≤80％ |
| Operating atmospheric pressure | 86kPa～106kPa |
| Transportation and storage temperature | -20 ~ +55°C |
| Transportation and storage humidity | 10%~93%,(including condensation) |
| Transportation and storage atmospheric pressure | 700~1060h |
Chair Comes Packed in either wooden box or separate parts in different corrugated boxes.
Warranty on The UP/Down & Back rest Motor is 4 years.
Warranty on the chair is 2 years. All the functioning part of chairs are covered. Any malfunction of the chair parts will be either repaired or replaced.
Any physical damage to the chair is not included in the warranty part. Any chair part malfunctioning due to physical damage is not covered under warranty .
For warranty to be applicable Voltage Stabilizer in working condition must be installed .
